GoPro Recovery
GoPro Recovery

Cameras supported

All current GoPro cameras will be

supported

GoPro do a range of video cameras. Each one has different ways that data is recorded, and so the recovery process is different for each one.  The notes below describe some of the main features of each recording method. o GoPro Hero o GoPro Hero 2 o GoPro Hero 3.  Supports multiplexed low and high resolution recording. o GoPro Hero 4.  Supports multiplexed low and high resolution recording. o GoPro Hero5.  Supports multiplex low and high resolution recording GoPro Base model.  This camera records data out of sequence with the second part of the logical file recorded first. The video data does include JPEG images, often used as a file thumbnail GoPro Hero 2 Technically it is very similar to the Hero 3 described below, but only supports high resolution video GoPro Hero 3 This camera saves the video data with high and low resolution physically interleaved on the memory chip.  Once all
video data is saved, then both header blocks (ftyp and moov) are written.  To recover the data it is necessary to determine which data block belongs to which data stream, high or low resolution, and to which ftyp and moov atom.  It is not possible to do this type of recovery by data carving but the GoPro recovery software is the result of extensive development to resolve this problems.  The result is normally perfect low resolution video and extremely good high resolution.  Occasionally on FAT32 memory chips, there may be a small glitch on high resolution video - a small problem we hope ultimately to resolve. JPEG files may also be saved on the memory chip. To recover unfinalised, or truncated video it is necessary to locate the start of a possible data run.  This will be at the start of a cluster, but there are at least two variations where the first frame starts at offset 0, or offset 4.  Once detected, the video stream is then reconstructed, and the moov atom created to allow the video to be played.  This is currently under development for the forensic version of the software including separating two interleaved video streams. GoPro Hero 4 and Hero 5 The Hero 4 range is similar to the Hero 3 above except the order of the atoms is different. On the Hero 4 and Heero 5 the ftyp is immediately followed by the mdat.  At the end of the recording, the moov atom is added.  As in Hero 3 high and low resolution streams are interleaved give the same recovery issues.  JPEG files may also be saved on the memory chip.  On the Hero 5, the high qualtity audio saves .wav files, also interleaved with the video stream.

The developers are not aware of any other software program

that can recover video from the memory chip where the data

streams are all interleaved, and out of logical sequence.

© GoPro Recovery
GoPro Recovery

Cameras

supported

All current GoPro

cameras will be

supported

GoPro do a range of video cameras. Each one has

different ways that data is recorded, and so the

recovery process is different for each one.  The notes

below describe some of the main features of each

recording method.

GoPro Hero

GoPro Hero 2

GoPro Hero 3.  Supports multiplexed low and high

resolution recording.

GoPro Hero 4 and 5.  Supports multiplexed low

and high resolution recording.

GoPro Base model.

This camera records data out of sequence with

the second part of the logical file recorded first.

The video data does include JPEG images, often

used as a file thumbnail

GoPro Hero 2

Technically it is very similar to the Hero 3

described below, but only supports high

resolution video

GoPro Hero 3

This camera saves the video data with high and

low resolution physically interleaved on the

memory chip.  Once all video data is saved, then

both header blocks (ftyp and moov) are written.

To recover the data it is necessary to determine

which data block belongs to which data stream,

high or low resolution, and to which ftyp and

moov atom.  It is not possible to do this type of

recovery by data carving but the GoPro recovery

software is the result of extensive development to

resolve this problems.  The result is normally

perfect low resolution video and extremely good

high resolution.  Occasionally on FAT32 memory

chips, there may be a small glitch on high

resolution video - a small problem we hope

ultimately to resolve. JPEG files may also be saved

on the memory chip.

To recover unfinalised, or truncated video it is

necessary to locate the start of a possible data

run.  This will be at the start of a cluster, but there

are at least two variations where the first frame

starts at offset 0, or offset 4.  Once detected, the

video stream is then reconstructed, and the moov

atom created to allow the video to be played.  This

is currently under development for the forensic

version of the software including separating two

interleaved video streams.

GoPro Hero 4 and Hero 5

The Hero 4 range is similar to the Hero 3 above

except the order of the atoms is different. On the

Hero 4 the ftyp is immediately followed by the

mdat.  At the end of the recording, the moov atom

is added.  As in Hero 3 high and low resolution

streams are interleaved give the same recovery

issues.  JPEG files may also be saved on the

memory chip.

The developers are not aware of any other software

program that can recover video from the memory chip

where the data streams are all interleaved, and out of

logical sequence.
